Udderly Quiet® Acoustic Panel – 200 Series

  • Easy Install

  • Made in USA

Udderly Quiet® Acoustic Panel – 200 Series

The 200 Series Acoustic Panel is our General All-Around, All-Purpose Acoustic Panel. This Acoustic Panel Model is our Most Popular and Best Selling panel due to Excellent Acoustic Performance, Limitless Design Options and Affordability.

Perfect for: Any and All Applications where Noise and Reverberation (Echo) is an issue. Common applications for these Acoustic Panels include: Offices, Restaurants, Schools, Worship Centers, Churches, Hotels, Home Theaters, Recording Studios and Homes.

Read More

Call Us

10% off Udderly Quiet Acoustic Panels until April 1st, 2024. Call for details: 866.949.9269

Specifications
Size Availability Up to 4 ft. x 10 ft., Large format panels are available. See 250 Series
Thickness 1 inch and 2 inch
Tolerance +/- 1/4 inch
Core 6 lb. Acoustical Glass Mineral Wool
Covering Acoustic Fabric
Edge Detail Resin Hardened
Edge Profile Square, Bevel, Rounded, Miter
Mounting Adhesive, Z-clip, Hook and Loop, Magnet
General Application Walls and Ceilings
Mounting Surface All Surfaces including Drywall, Brick & Concrete
Flammability Class A™ – Does not exceed 25 Flame Spread, 50 Smoke Developed when tested in accordance with ASTM E84, UL 723 and NFPA 255.
Indoor Air Quality Certified as a low emitting product by the GREENGUARD Environmental Institute to both the GREENGUARD Certification Program and the more stringent GREENGUARD Children and Schools standard.

Udderly Quiet® 200 Series Acoustic Panels

The 200 Series — part of the Udderly Quiet® family of products — is a general-purpose, modular soundproofing panel that offers flexibility and performance at an affordable price point. It’s one of our best-selling products, and an excellent choice for everything from recording studio and rehearsal space use to more general soundproofing applications.

200 Series panels feature a glass mineral wool core and fabric covering. Glass mineral wool offers excellent noise reduction and low weight, allowing for a variety of installation options. For additional protection, panel edges are dipped in a special resin hardener that increases their strength. As a result, 200 Series products are some of the most durable all-purpose acoustic panels on the market today.

Product Options

The popularity of our 200 Series all-purpose acoustic panels is due in part to the extensive customization options we offer. Panels are available in 1” or 2” thicknesses, with square, beveled, mitered or rounded edges, and in any of more than 1,000 fabric options. Standard sizes range up to 4’ by 10’, though large format panels are available by special request.

Installation Made Easy

200 Series panels can be installed with magnets, Z-clips or Velcro, or with a special adhesive to fix them in place permanently. We can help you determine the optimal number and best placement of 200 Series panels for any room. Contact Soundproof Cow directly for a free acoustic assessment and a quote for a complete set of noise reduction panels and related accessories.

Wish you could hear the difference our acoustic panels make before purchasing?
Check out our sound test!
Clap Sound Wave Listen

If you want the Best Acoustic Performance, Unlimited Covering Options, the Most Environmentally Friendly Acoustic Panel on the planet all wrapped up into an Affordable package, You’ve Found It!

Superior Acoustic Performance — Udderly Quiet® Acoustic Panels are our premium sound absorption product and can be used anywhere reverberation (echo) is an issue. Our acoustic panels will improve speech intelligibility, improve production and improve any listening or recording environment. Udderly Quiet® Acoustic Panels absorb noise generated at low, mid and high frequencies.

Exceptional Quality — Udderly Quiet® Acoustic Panels are meticulously hand-made by experienced craftsmen that take pride in the product they build. Only the highest quality materials available are used to make this highly finished professional product.

In-stock Options — We have a large variety of Udderly Quiet® Acoustic Panels in-stock with different fabric options and in multiple dimensions. Most of our in-stock acoustic panels are shipped the same day they are ordered and arrive at your project in three business days.

Ease of Installation — Udderly Quiet® Acoustic Panels are light weight and can be attached to a variety of surfaces. Basic hand tools and a limited amount of construction know how is all that are needed to ensure a proper installation. Udderly Quiet® Acoustic Panels can be cut or trimmed on the job site with simple hand tools. Our Acoustic Panels can be mounted permanently with adhesive or temporarily with Hook & Loop or Z-Clips.

Endless Design Potential — Udderly Quiet® Acoustic Panels are custom built to your specifications. Architectural interest is added by ordering our panels with square, beveled, mitered or rounded edges.

Fabric Covering Variety — Udderly Quiet® Acoustic Panels are available with an endless variety of fabric options. Choose the fabric color and texture that best matches your existing décor. If desired, we will match your fabric of choice.

Durability — Udderly Quiet® Acoustic Panels come with resin hardened edges. The Acoustical Glass Mineral Wool core of our acoustic panels is firm and resists impacts.

Excellent Flammability Rating — Our Udderly Quiet® Acoustic Panels have a Class A™ flammability rating. This product passes most building code flammability requirements for exposed materials.

Versatile — Udderly Quiet® Acoustic Panels are a great office accessory for posted messages or need to know information. Panels covered with the FR701 fabrics work with hook & loop Velcro® and are tackable.

Size Options

Thickness Options

  • 1 inch
  • 2 inch

Popular Fabric Options

Top 5 FR701 fabrics Click to Enlarge
FR701 Eggshell
Eggshell
FR701 Wheat
Wheat
FR701 Quartz
Quartz
FR701 Grey Mix
Grey Mix
FR701 Black
Black



Top 5 Anchorage fabrics Click to Enlarge
Anchorage Birch
Birch
Anchorage Sunshine
Sunshine
Anchorage Goose
Goose
Anchorage Asteroid
Asteroid
Anchorage Fossil
Fossil

Ordering Information

Click the “Request a Quote” button to tell us about your project. One of our Acoustic Pros will contact you when your quote is ready. Quotes usually take about an hour!

If you need a quote quickly and would rather talk to a warm body, then dial 1-866-949-9269. No pushy sales guys…promise.

Product Data Sheet

Tech Specs

Here is some Technical Info you probably don’t want to read, but should know!

Size Availability: Up to 4 ft. x 10 ft., Large format panels are available.
See 250 Series

Thickness: 1 inch and 2 inch

Tolerance: +/- 1/4 inch

Core: 6 lb. Acoustical Glass Mineral Wool

Covering: Acoustic Fabric

Edge Detail: Resin Hardened

Edge Profile: Square, Bevel, Rounded, Miter

Mounting: Adhesive, Z-clip, Hook and Loop, Magnet

General Application: Walls and Ceilings

Mounting Surfaces: All Surfaces including Drywall, Brick & Concrete

Flammability: Class A™ – Does not exceed 25 Flame Spread, 50 Smoke Developed when tested in accordance with ASTM E84, UL 723 and NFPA 255.

Indoor Air Quality: Certified as a low emitting product by the GREENGUARD Environmental Institute to both the GREENGUARD Certification Program and the more stringent GREENGUARD Children and Schools standard.

Green Information:

Our Acoustic Glass Mineral Wool is made with 50% Recycled Post-Consumer materials. In other words, the same bottles you recycle every week!

The other 50% of our Acoustical Glass Mineral Wool is made from one of the most abundant renewable resources on the planet- sand.

The Binder used in our Acoustical Glass Mineral Wool reduces embodied energy by 70%, which means there is 70% less binder agent needed when compared to other glass wools and acoustic fiberglass products.

All of our Acoustic Fabrics are 100% Recycled Polyester.

Acoustic Data

THICKNESS COVERING DENSITY 125 250 500 1000 2000 4000 NRC*
1 INCH fabric 6 lbs .05 .26 .77 1.04 1.04 1.03 0.80
1 INCH vinyl 6 lbs .19 .36 .82 1.12 1.00 .80 0.85
2 INCH fabric 6 lbs .25 .89 1.17 1.16 1.10 1.08 1.10
2 INCH vinyl 6 lbs .32 .81 1.08 1.06 1.03 1.04 1.00

* NRC = noise reduction coefficient

Acoustic Panel Edge Profiles

square edge acoustic panel

beveled edge acoustic panel

round edge acoustic panel

mitered edge acoustic panel

Acoustic Panel Corner Options

square corner acoustic panel rounded corner acoustic panel

Acoustic Panel Patterns

Need a couple ideas to get the creative juices flowing? Check out these Acoustic Panel Patterns! All of these designs are Modular and can be resized.It’s simple.

Choose your Pattern. Choose your Fabric. Decorate your space!

Click to Enlarge
Solo™
Acoustic Panel Pattern Card Solo
Adobe Reader
Patch™
Acoustic Panel Pattern Card Patch
Adobe Reader
Pixel™
Acoustic Panel Pattern Card Pixel
Adobe Reader

FAQs

What exactly is the 200 Series Udderly Quiet® Acoustic Panel?

The Udderly Quiet® 200 series Acoustic Panel consists of an Acoustical Glass Mineral Wool core wrapped in an Acoustic Fabric. The edges of this Acoustic Panel are dipped in a resin hardener to protect the edges, add strength and increase the life of the Acoustic Panel.

What is an Acoustic Fabric and what are my options?

An Acoustic Fabric is a fabric that is considered acoustically transparent. All Acoustic Fabrics have whats called an “Open Weave” which allows sound to travel through the fabric material and into the sound absorbent core. There are 1000’s of Acoustic Fabric Options.

Do I have to use one of your fabrics or can I provide my own?

These are your panels! We will wrap them in whatever fabric you choose. All we ask is that you send us a 36 inch x 36 inch sample of fabric so we can test it out. We want to make sure the adhesive bonds the materials properly and also make sure the adhesive doesn’t “bleed” through the fabric and create spots on the face of the panel.

How Big can I get the 200 Series Acoustic Panels?

The largest we can construct a seamless 200 Series Acoustic Panel is up to 4 ft. x 10 ft. For Larger Acoustic Panels, check out the 250 Series and the 350 Series. Those models have Aluminum Frames which allows for larger panel construction.

What Shapes are available with the 200 Series Acoustic Panels?

These panels are totally customizable. We can make anything from rectangles to circles to free-form shapes. Some of our clients have provided patterns of modular designs. Check out our Udderly Quiet® Acoustic Panels Gallery for some creative ways to use these Acoustic Panels.

What are the Most Economical sizes for Acoustic Panels?

Any Panel where one of the dimensions is 4 foot. 2 ft. x 4 ft., 4 ft. x 4 ft., 4 ft. x 5 ft., 4 ft x 8 ft. and 4 ft. x 10 ft. are the most popular and economical sizes for Acoustic Panels.

What Edge Profiles are available for the 200 Series Acoustic Panels?

We offer these panels with Square, Beveled, Mitred and Rounded edges. The Square and Beveled Profiles are by far the most popular.

How Many Acoustic Panels do I need?

We use Proprietary Acoustic Software and information from you about your space to answer this question. We use three main criteria to determine how much acoustic material is needed. First, we need to know the Dimensions (Length, Width and Height) of the Room or Space that is being treated. Typically, the larger the space the more Acoustic Panels are needed to drop the reverb time to a preferred level.

Second, we need to know the existing Wall, Ceiling and Floor construction materials. All Construction materials like Drywall, Concrete, Brick, Metal, Wood and Carpet have industry accepted inherent Acoustic Values that affect the acoustics of the space. We know these values and use them to help determine how much Acoustic Material is needed to get the desired results.

Third, we need to know How the Space is being used or the function of the space. The use of the space greatly affects the amount of absorption materials needed to achieve the desired results. Different spaces require different reverberation times. For example, A Recording Studio requires a much lower reverb time than an Office environment. A Restaurant requires a different reverb time than a Home Theater. We know the Industry accepted reverb times for a multitude of spaces and use these times when determining the amount of acoustic coverage.

The Fastest and most thorough way to find out how many panels you need is to call our Acoustic Team at 1-866-949-9269. Usually, you will have your answer in few short minutes. OR check out our Free Online Acoustic Analysis. Fill out the form and one of our consultants will respond!

How Much do these Acoustic Panels Cost?

The cost of this product varies greatly due to the multitude of sizes, configurations, covering options and the fact that each project is unique in terms of the amount needed to get the desired results.
The Best way to get a quote is to contact our Acoustic Team at 1-866-949- 9269. For most projects you will have a quote in hand in a few minutes.

Another viable option is to complete your Free Online Acoustic Analysis. A member from our Acoustic Team will contact you via email when your quote is ready!

How Long will it take to get my Acoustic Panels?

On average, it will take about 3-4 weeks from the time you place your order to delivery. However, our lead times may vary depending on production flow. Contact a member of our Acoustic Team to find out what the current Lead Time is for Acoustic Panels. 1-866-949-9269.Need it sooner? No worries. We can expedite orders to be delivered in 10 days!

Adhesive

Adhesive Panel MountingAdhesive mounting is ideally suited for permanent applications requiring speed and ease of installation. This type of installation requires little to no layout time depending on various field conditions. Use this method if there is a potential for impact or other stresses. The adhesive method provides the strongest bond between panel and wall.

Z-clip

Z-clip Panel MountingZ-clip mounting is ideal for applications where frequent panel removal & re-hanging is required. This type of installation demands careful planning and layout before the panels are placed on the wall. This type of mounting method will not support more weight than the panel itself. Panels mounted with Z-clips cannot be subjected to peel away stress as this may cause a failure of panel to Z-clip bond.

Options
